Шестерни понижающие РК 3.3 33% Marks 4WD Adaptors MFK30300 для Toyota Land Cruiser 105 70
Part Number: MFK30300
Extra Low Range Transfer Case Gears for Toyota Land Cruiser 33% Reduction
To Suit - HF1A (19 spline input) Transfer case:
- Toyota Land Cruiser - VDJ76 Series
- Toyota Land Cruiser - VDJ78 Series
- Toyota Land Cruiser - VDJ79 Series
- Toyota Land Cruiser - 105 Series (19 spline part-time 4WD models only)
All of our Low Range Gears are Australian Made
Extra Low Range Transfer Case Gears For Toyota Land Cruiser 70 and 105 series HF1A Transfer case
These gears have been designed to directly replace the Toyota Land Cruiser part-time 4WD HF1A transfer case (19 spline input) low range gears as fitted to VDJ70, HZJ105 and HZJ105.
Vehicles fitted with automatic transmissions, standard or other wise can also take advantage of the extra low gearing in low range as a dramatic improvement in engine braking is achieved giving much improved off road performance and increased safety.
Vehicles fitted with larger tyres can regain lower than original gearing when fitted with these gears. For example; 35" tyres will increase the ground speed of your vehicle by approximately 13%, with Marks 4WD low range gears fitted you will still have a 20% lower overall ratio than a standard vehicle.
| Original Toyota Gearing Ratio | Marks 4WD Low Range Gear Ratio | |
| High Range | 1:1 | 1:1 = No Change |
| Low Range | 2.488:1 | 3.3:1 = 33% Reduction |
Low range ratio 3.3:1 or 33% Reduction
Manual Gearbox: 5-speed manual - H150F.
The gear ratios are: 1st 4.529:1, 2nd 2.464:1, 3rd 1.49:1, 4th 1:1, 5th .881:1, reverse 4.313:1
Multiply the extra low ratio of 3.3:1 by the 1st gear ratio of 4.529:1 and the differential ratio of 3.9:1 this will give you a final drive ratio of 58.28:1 which is a vast improvement on the standard final drive ratio of 43.95:1
